How To Make A Helmet From Pep To Finish

Status
Not open for further replies.
Amazing, this is answering so many questions. Keep it up ben these videos are awesome. I have another question though fiberglass is a little lighter but have you noticed any difference in the strength of each? Does one provide more strength than the other?



Oh, and could you maybe show how to do this with another piece of armor? Like the ODST WETA shins I'm working on currently? From watching you I've been thinking I'll just have to paint it on with the brush.

Trigger said:
Amazing, this is answering so many questions. Keep it up ben these videos are awesome. I have another question though fiberglass is a little lighter but have you noticed any difference in the strength of each? Does one provide more strength than the other?



Oh, and could you maybe show how to do this with another piece of armor? Like the ODST WETA shins I'm working on currently? From watching you I've been thinking I'll just have to paint it on with the brush.





You would only have to brush it on sir, so you are correct. I actually already did some odst shins, although mine were a scratch build. I used mat-board which is already quite sturdy, so there wasn't mush re-enforcing needed. However for yours (cardstock I assume) I would resin the outside first then just paint in or slush cast the rondo.

Last edited by a moderator:
so to ask another question,..would rondo,bondo or resin jelly be best (easiest) for the outside to shape and smooth? after hardening the inside

I mentioned jelly, because I read somewhere, one of the people on the 405th used it instead of bondo and it was easier to sand, was curious if you had

any experience w/ it. couldnt find anything more on it.

amancue said:
so to ask another question,..would rondo,bondo or resin jelly be best (easiest) for the outside to shape and smooth? after hardening the inside



Of those it would be bondo. It is basically a putty that sands very easily. I will be working with it later in the build.

Last edited by a moderator:
BenStreeper said:
Of those it would be bondo. It is basically a putty that sands very easily. I will be working with it later in the build.



another thought I was having maybe you can help w/ this one of the pieces I have to work on, is a closed object, and I've

been thinking of many different ways to handle it, Im wondering how well rondo would adhere to a surface already resin'ed

so I cant 'glass it up then do the final stiffening ontop of it, another thought is more pains taking, carefully glass the

inside of each piece before I put it together leaving the tabs clean then build it so its stiffer from the inside then

coating the outside

Last edited by a moderator:
amancue said:
another thought I was having maybe you can help w/ this one of the pieces I have to work on, is a closed object, and I've

been thinking of many different ways to handle it, Im wondering how well rondo would adhere to a surface already resin'ed

so I cant 'glass it up then do the final stiffening ontop of it,



Rondo uses resin inside of it as a thinning agent. This makes it very adherent to already resined pieces (providing of course you are using the same resin.) As for the "closed objects" : first resin the outside so that the object will not lose its shape/ warp. Next examine your object for a flat spot. EXAMPLE: on an AR you would be looking at the back of the butt, or the bottom of the clip. Then cut about a 2inch hole to pour in the RONDO. Rotocast it in the piece. Then pour in more rondo as needed. Once the piece is "hard" enough (some one out there just said "giggitty") pour in one more small batch of rondo. Once it is in put a piece of packing tape over the hole. Let the rondo harden then simply remove the tape.



amancue said:
another thought is more pains taking, carefully glass the

inside of each piece before I put it together leaving the tabs clean then build it so its stiffer from the inside then

coating the outside



This just wont work well.

Last edited by a moderator:
BenStreeper said:
Rondo uses resin inside of it as a thinning agent. This makes it very adherent to already resined pieces (providing of course you are using the same resin.) As for the "closed objects" : first resin the outside so that the object will not lose its shape/ warp. Next examine your object for a flat spot. EXAMPLE: on an AR you would be looking at the back of the butt, or the bottom of the clip. Then cut about a 2inch hole to pour in the RONDO. Rotocast it in the piece. Then pour in more rondo as needed. Once the piece is "hard" enough (some one out there just said "giggitty") pour in one more small batch of rondo. Once it is in put a piece of packing tape over the hole. Let the rondo harden then simply remove the tape.







This just wont work well.



the 2nd I didnt think would just a random I did I had while thinking,. .your 1st suggestion is similar to one of my original ideas of putting a small hole in it and measuredly spraying in great stuff PU foam (after glassing the outside of course) the piece in question is the backpack for the Imperial Space Marine (Warhammer 40k) hmmm the casting it around would prolly work, it'll just take a while its about 725MM 2.25feet high,but Im feeling more confident that it'll work by the time I get to that part

Last edited by a moderator:
amancue said:
my original ideas of putting a small hole in it and measuredly spraying in great stuff PU foam (after glassing the outside of course) the piece in question is the backpack for the Imperial Space Marine (Warhammer 40k)





I'll tell you this ahead of time. If you are going to use the great stuff you are better off getting Flex-it from Reynolds. Great stuff was responsible for exploding more than one of my helmets in the past :( It's just not as predictable as Flex-It due to the way it's Chemical Reaction expands. Using Oxygen was smart on their part but will cause problems for anything in a "contained" space........





Poor, poor ODST Rookie helmet v1







I still miss you



Last edited by a moderator:
BenStreeper said:
I'll tell you this ahead of time. If you are going to use the great stuff you are better off getting Flex-it from Reynolds. Great stuff was responsible for exploding more than one of my helmets in the past :( It's just not as predictable as Flex-It due to the way it's Chemical Reaction expands. Using Oxygen was smart on their part but will cause problems for anything in a "contained" space........





Poor, poor ODST Rookie helmet v1







I still miss you



yeah that's what I've heard,.. I used it on my Anti-Material Rifle and it didnt do too bad a job, but had multiple coats of resin on the outside and still had to wait it,.. and occasionly squeeze certain area;s flat while it was still more fluid to keep it nice,. so I was looking to other alternative's so to make sure I understood one of your earlier statements you said rondo would adhere just fine to a resined surface, IE the outside, but you'd still reccomend doing it to the inside instead?


Last edited by a moderator:
I am about to start my first serious strengthening thingy (before, I was really cheap and only made paper helms and painting right on the paper.) and I was reviewing the safety stickies and they say that you're supposed to wear safety goggles? Also, for the respirator, apparently you're supposed to refill the cartridges? How often would they need to be refilled?

amancue said:
yeah that's what I've heard,.. I used it on my Anti-Material Rifle and it didnt do too bad a job, but had multiple coats of resin on the outside and still had to wait it,.. and occasionly squeeze certain area;s flat while it was still more fluid to keep it nice,. so I was looking to other alternative's so to make sure I understood one of your earlier statements you said rondo would adhere just fine to a resined surface, IE the outside, but you'd still reccomend doing it to the inside instead?



Both work fine I just prefer inside



CrunchbiteNuva said:
I am about to start my first serious strengthening thingy (before, I was really cheap and only made paper helms and painting right on the paper.) and I was reviewing the safety stickies and they say that you're supposed to wear safety goggles? Also, for the respirator, apparently you're supposed to refill the cartridges? How often would they need to be refilled?



refill any time you can smell the resin, and use goggles when you sand, or a face shield. Also gloves are a must sir.

Last edited by a moderator:
You already answered a fiberglass question above, but this is kind of different.



I have seen someone on the forums rondo something, then place fiberglass cloth onto the semi-wet rondo, then finish with another layer of rondo on top of that. Would there be any benefits to this method over yours? What would the pro/cons of this and your method be?



Thanks for all the great videos man!

Neoproks said:
You already answered a fiberglass question above, but this is kind of different.



I have seen someone on the forums rondo something, then place fiberglass cloth onto the semi-wet rondo, then finish with another layer of rondo on top of that. Would there be any benefits to this method over yours? What would the pro/cons of this and your method be?



Thanks for all the great videos man!



Yes, adding fiber glass to any resin based mixture will make the mixture tuffer. This goes not only for rondo, but also for most Smoothcast Plastics as well. The con of this method is that it would not be as hard as if you did a regular resined fiberglass coat, and then poured rondo on top. In my personal opinion not only is this fiber-glassing into rondo a waste of time, but not necessary at all. If you want to do a light coat of rondo, then add fiberglass with regular resin, then another coat of rondo. That would be much stronger, and cost you less money in the long run.

Last edited by a moderator:
BenStreeper said:
Yes, adding fiber glass to any resin based mixture will make the mixture tuffer. This goes not only for rondo, but also for most Smoothcast Plastics as well. The con of this method is that it would not be as hard as if you did a regular resined fiberglass coat, and then poured rondo on top. In my personal opinion not only is this fiber-glassing into rondo a waste of time, but not necessary at all. If you want to do a light coat of rondo, then add fiberglass with regular resin, then another coat of rondo. That would be much stronger, and cost you less money in the long run.



got a question for you,..after just having tried my 1st batch of rondo.

did you already cut the bondo in your can, mine would not mix that easily

it was like trying to mix taffy or maybe bread dough, next batch I'll

make a bit more watery too thick

Last edited by a moderator:
amancue said:
got a question for you,..after just having tried my 1st batch of rondo.

did you already cut the bondo in your can, mine would not mix that easily

it was like trying to mix taffy or maybe bread dough, next batch I'll

make a bit more watery too thick



I got them to shake it up with the paint mixer at lowes :)

Last edited by a moderator:
